Heavy Duty Concave Blades and 1 5/8: Coil-Tech Coulter II Blade Mount
The I-4200 is one of Salford’s next generation, patented, hybrid vertical tillage tools. Designed to combine the residue mixing capabilities of a disc with the field finish characteristics of a cultivator – the Salford I-4200 has it all.
The I-4200 has 5 inch blade spacing overall, with two rows of 22 inch concave blades followed by two rows of 22 inch wavy coulters. The coulters are carried by the heavy Coil-Tech II blade mount that improve Salford’s ground penetration while maintaining the industry leading clearance and obstacle protection.
The front two rows of concave blades have the power to level ruts and maximize residue incorporation. The rear two rows of 22 inch wavy blade coulters improve residue sizing and incorporation, accelerating residue break down and warming seedbeds. This superior seedbed preparation improves planter seed placement, promoting more even, rapid, germination without creating density layers that can slow and stunt plant growth. The combination of independently mounted blade types provides effective mechanical weed control, stronger performance in high-residue or wet conditions compared to compact discs or disc gang-style VT machines.
The I-4200 can be equipped with Salford’s FlexFinish hydraulically adjustable attachments for additional versatility. FlexFinish hydraulically adjustable tine harrows and rolling baskets allow the finishing attachments to be adjusted to residue volume and varying field moisture without leaving the cab.
Coulters and Mounts
- Front:22” dia a 5 mm shallow concave discs (rubber mount)
- Rear: 22” dia x 5mm 8 wave coulter (coil Mount)
- Boron steel blades
- 5” of vertical travel
Frame
- Heavy Duty 4”x 6” tubing
- Hydraulic level lift
- Hydraulic single-point depth control
- Heat treated cast clevis hitch
- Operator convenience center
- Welded main frame with capped tube ends
Tires—Mainframe
- 16’ - 31’ 8 bolt 305/70 x R22.5
- 36’ - 41’ (3 Section) 8 bolt 425/70 x R22.5
- 41’ (5 Section) 10 bolt 425/65R x 22.5
- 50’ (5 Section) 10 bolt 445-65R x 22.5
Tires—Wings
- 20’ – 41’ All Wings
- 11L x 15 6 bolt load range “D"
- 50’ – All Wings
- 305/70R x 22.5 8 bolt tires”
Finishing Package
- FlexFinish Hydraulically Adjustable Tines and Rolling Baskets (28' and up only)
- Manually Adjustable HD Tines and Rolling Baskets
Finishing Package Consist of:
- Heavy Duty 3 Bar 1/2” Tines
- 1/2” dia. tine, strength for exceptional leveling
- 3 ranks with 20” clearance
- No tool pitch adjustment
- Heavy Duty 14” Rolling Harrow
- Adjustable down pressure
- Triple seal 1.5” bearing resists rock damage, even at high speed
- Flex finish hydraulically adjustable rolling harrow (Optional, 28' and up only)
- 100-lb. Weight Kits
- Adjustable Tow Hitch (one-man connection)
- Hydraulic Lines and Quick Coupler to Tow Hitch
- Axle Pivot Grease Bank
- Roller Dirt Shield
- Salford 4200 Jackhammer Effect
- Our First Salford Demo of 2021
- What Do the Salford Tool Numbers Mean? Which one Fits You?
- Bury Residue In The Fall and Create Great Seedbeds In The Spring
- When Should You Change Salford Blades?
- Valmar/Salford Combo Incorporating Cover Crops
- Salford I-4200 Independent Series
Product Description
Heavy Duty Concave Blades and 1 5/8: Coil-Tech Coulter II Blade Mount
The I-4200 is one of Salford’s next generation, patented, hybrid vertical tillage tools. Designed to combine the residue mixing capabilities of a disc with the field finish characteristics of a cultivator – the Salford I-4200 has it all.
The I-4200 has 5 inch blade spacing overall, with two rows of 22 inch concave blades followed by two rows of 22 inch wavy coulters. The coulters are carried by the heavy Coil-Tech II blade mount that improve Salford’s ground penetration while maintaining the industry leading clearance and obstacle protection.
The front two rows of concave blades have the power to level ruts and maximize residue incorporation. The rear two rows of 22 inch wavy blade coulters improve residue sizing and incorporation, accelerating residue break down and warming seedbeds. This superior seedbed preparation improves planter seed placement, promoting more even, rapid, germination without creating density layers that can slow and stunt plant growth. The combination of independently mounted blade types provides effective mechanical weed control, stronger performance in high-residue or wet conditions compared to compact discs or disc gang-style VT machines.
The I-4200 can be equipped with Salford’s FlexFinish hydraulically adjustable attachments for additional versatility. FlexFinish hydraulically adjustable tine harrows and rolling baskets allow the finishing attachments to be adjusted to residue volume and varying field moisture without leaving the cab.
Coulters and Mounts
- Front:22” dia a 5 mm shallow concave discs (rubber mount)
- Rear: 22” dia x 5mm 8 wave coulter (coil Mount)
- Boron steel blades
- 5” of vertical travel
Frame
- Heavy Duty 4”x 6” tubing
- Hydraulic level lift
- Hydraulic single-point depth control
- Heat treated cast clevis hitch
- Operator convenience center
- Welded main frame with capped tube ends
Tires—Mainframe
- 16’ - 31’ 8 bolt 305/70 x R22.5
- 36’ - 41’ (3 Section) 8 bolt 425/70 x R22.5
- 41’ (5 Section) 10 bolt 425/65R x 22.5
- 50’ (5 Section) 10 bolt 445-65R x 22.5
Tires—Wings
- 20’ – 41’ All Wings
- 11L x 15 6 bolt load range “D"
- 50’ – All Wings
- 305/70R x 22.5 8 bolt tires”
Finishing Package
- FlexFinish Hydraulically Adjustable Tines and Rolling Baskets (28' and up only)
- Manually Adjustable HD Tines and Rolling Baskets
Finishing Package Consist of:
- Heavy Duty 3 Bar 1/2” Tines
- 1/2” dia. tine, strength for exceptional leveling
- 3 ranks with 20” clearance
- No tool pitch adjustment
- Heavy Duty 14” Rolling Harrow
- Adjustable down pressure
- Triple seal 1.5” bearing resists rock damage, even at high speed
- Flex finish hydraulically adjustable rolling harrow (Optional, 28' and up only)
Options
- 100-lb. Weight Kits
- Adjustable Tow Hitch (one-man connection)
- Hydraulic Lines and Quick Coupler to Tow Hitch
- Axle Pivot Grease Bank
- Roller Dirt Shield
