Halo VRT performs the job of multiple tillage machines faster.
The HALO VRT is an unprecedented tillage design. This is the industry’s first variable-rate tillage design on a forward folding, high-speed disk frame.
The HALO VRT’s wide range of gang angle adjustments allows it to perform spring and fall operations with ease. HALO is Salford’s next generation of tillage implements combining agronomic performance with new equipment technology for fast operation, ease of use, lower maintenance, and safer transport.
HALO VRT takes this revolutionary new tillage platform to the next level with hydraulically adjustable gangs. This new machine allows producers to choose their tillage intensity on the fly, from the comfort of the tractor cab. Whether adjustments are needed in the field, from field to field, or from season to season the HALO VRT performs the work of multiple tillage machines in one simple-to-operate platform.
HALO VRT joins the HALO HSD and HALO AerWay in this new tillage series of tillage implements from the Salford Group.
Coulter Angle Adjustments
Salford’s engineering and product management teams worked to perfect the adjustments of the coulter angles of the HALO VRT with adjustments from 2°-15°.
These adjustments transform the HALO VRT from a vertical tillage and seedbed prep tool all the way to a fall tillage machine capable of leveling ruts.
Hydraulic On-The-Go Adjustments
Hydraulic adjustments are made easy with the HALO VRT. There are no pins, no reason to get out of the cab. With the simple push of a button, the adjustments you wish to make are made from the comfort of the cab.
Easy to operate
The HALO VRT is simple to set! Single point depth control, hydraulic fore/aft leveling, and active pressure control on the finishing tool. Anyone can operate this machine.
The VRT’s depth control is totally hydraulic. There are no shims or plates required to control the depth.
The operator convenience station keeps implement connections protected, organized, and at the operator’s fingertips. The color-coded hose grips take out the guesswork when connecting Salford implements to the tractor.
The HALO’s narrow forward fold design makes the machine safe and easy to transport.
Low maintenance design
Durable, sealed, maintenance free hubs and finishing tool bearings mean much less downtime on the HALO VRT.
The HALO VRT has easily accessible grease points, the mainframe hinges, axles, wings, and roller frames.
Specifications | |||||
---|---|---|---|---|---|
Model Size | 20 foot (6.096 m) |
25 foot (7.62 m) |
30 foot (9.144 m) |
35 foot (10.668 m) |
40 foot (12.192 m) |
Approximate Weight (lbs) | 18,800 | 21,476 | 28,335 |
31,161 |
34,000 |
Driving Interval | 19 ft. 1 in. | 24 ft. 1 in. | 29 ft. 2 in. | 34 ft. 1 in. | 39 ft. 1 in. |
Concave Blades | 48 | 60 | 72 | 84 | 96 |
Transport Height, Roller Cylinders Retracted |
15 ft. | 15 ft. 1 in. | 15 ft. 1 in. | 14 ft. 10 in. | 15 ft. 1 in. |
Transport Height Roller Cyliners Extended |
13 ft. 10 in. | 13 ft. 11 in. | 13 ft. 10 in. | 13 ft. 8 in. | 13 ft. 11 in. |
Transport Width, Roller Cylinders Retracted |
11 ft. 3 in. | 11 ft. 3 in. | 11 ft. 9 in. | 11 ft. 9 in. | 11 ft. 9 in. |
Transport Width Roller Cyliners Extended |
11 ft. 6 in. | 11 ft. 6 in. | 13 ft. 11 in. | 13 ft. 11 in. | 13 ft. 11 in. |
Frame Sections | 2 | 3 | |||
Mainframe structure | 6 in. x 6 in. tubular steel | 6 in. x 6 in. tubular steel | |||
Hitch Structure | 6 in. x 8 in. tubular steel | 6 in. x 10 in. tubular steel | |||
Tires, Mainframe | 600/50R22.5 10 bolt hub | 600/50R22.5 10 bolt hub | 800/40R22.5 10 bolt hub | ||
Tires, Wings | N/A | 31x13.5-15 tire | 500/50R22.5 8 bolt hub | ||
Drawbar Hitch | CAT 4 | CAT 5 | |||
Hitch | 8,000 lbs manual jack | Hydraulic jack with manual ball value | |||
Hydraulic Remotes Required Standard Plug to Tractor Hydraulics |
5 | 5+ | |||
Number of Hydraulics Required Electro-Hydraulic Joystick Option |
3 | 3 |
