Salford HALO - HSD

Please call 419-953-8500 for pricing.

Need more information about this product?

Call us at 419-953-8500.

The HALO HSD is engineered for level operation at speed and with the clearance needed for tough conditions. HALO HSD’s individually mounted blades allow for maximum residue and soil flow, while the angled blade mounting arms are designed to keep the HALO HSD at depth in hard ground.

HALO HSD has advanced hydraulic systems that are simple to operate. Fore/aft leveling, active down pressure, single point depth control, and finishing systems all have hydraulic adjustment that is easy to use.

High Speed and Highly Durable

  • High Clearance - Independently mounted blades allow for excellent soil and residue flow through the machine.
  • Excellent obstacle protection - Independently mounted blades with rubber torsion suspension are capable of up to 7.5 inches of vertical deflection for obstacle protection in rough and rocky conditions. Each blade faces rocks and obstacles on their own which lessens the load put on the HALO HSD frame.

Superior Leveling

  • HALO uses hydraulic wing down pressure with an accumulator to ensure level operation at high speeds.
  • HALO’s blades are tipped under which pulls the machine into the ground, ensuring that the implement stays at the proper operating depth, even in hard ground.

Easy to Operate

  • The HALO HSD is simple to set! Single point depth control, hydraulic fore/aft leveling and a single point control for setting pressure on the finishing tool.
  • The operator convenience station keeps implement connections protected, organized and at the operator’s finger tips. The color coded hose grips take out the guess work when connecting Salford implements to the tractor.
  • The HALO’s narrow forward fold design makes the machine safe and easy to transport.

Low Maintenance Design

  • Durable, sealed blade hubs make for much less maintenance on the HALO. The blades hubs can be rebuilt to save cost on seasonal maintenance.
  • The HALO has three easily accessible grease points, the main frame hinges, axles and roller frames.
  • HP Requirements of 12-18 HP/FT depending on working depth
  • Working depth 3 - 5”
  • Operating Speed of 8.5 mph minimum up to 14 mph
  • Front row blades on compound 14° open angle and 4° tipped under angle, 22” smooth low concavity blades
  • Rear row blades on compound 17° open angle and 4° tipped under angle, 22” notched low concavity blades
  • Net 5” spacing; 10” spacing per row
  • 4 piece rubber torsion suspension on coulter mounts
  • Blades hubs: Double tapered roller bearing, multi-lip sealed, maintenance free, re-buildable
  • Single point depth control
  • Single point finishing tool pressure
  • Hydraulic fore/aft leveling
  • Hydraulic Wing Down pressure / Accumulator Protection on tilt
  • Factory setup included; minimal finishing tool assembly. Must pin on finishing tools; hydraulics are pre-plumbed

Tires 600/50R22.5

Finishing Options

  • Standard 23" round bar cage roller
  • AVAILABLE SPRING 2021 - Optional 23" rubber packer roller with scraper system

Product Description

The HALO HSD is engineered for level operation at speed and with the clearance needed for tough conditions. HALO HSD’s individually mounted blades allow for maximum residue and soil flow, while the angled blade mounting arms are designed to keep the HALO HSD at depth in hard ground.

HALO HSD has advanced hydraulic systems that are simple to operate. Fore/aft leveling, active down pressure, single point depth control, and finishing systems all have hydraulic adjustment that is easy to use.

Features and Benefits

High Speed and Highly Durable

  • High Clearance - Independently mounted blades allow for excellent soil and residue flow through the machine.
  • Excellent obstacle protection - Independently mounted blades with rubber torsion suspension are capable of up to 7.5 inches of vertical deflection for obstacle protection in rough and rocky conditions. Each blade faces rocks and obstacles on their own which lessens the load put on the HALO HSD frame.

Superior Leveling

  • HALO uses hydraulic wing down pressure with an accumulator to ensure level operation at high speeds.
  • HALO’s blades are tipped under which pulls the machine into the ground, ensuring that the implement stays at the proper operating depth, even in hard ground.

Easy to Operate

  • The HALO HSD is simple to set! Single point depth control, hydraulic fore/aft leveling and a single point control for setting pressure on the finishing tool.
  • The operator convenience station keeps implement connections protected, organized and at the operator’s finger tips. The color coded hose grips take out the guess work when connecting Salford implements to the tractor.
  • The HALO’s narrow forward fold design makes the machine safe and easy to transport.

Low Maintenance Design

  • Durable, sealed blade hubs make for much less maintenance on the HALO. The blades hubs can be rebuilt to save cost on seasonal maintenance.
  • The HALO has three easily accessible grease points, the main frame hinges, axles and roller frames.

Standard Features

  • HP Requirements of 12-18 HP/FT depending on working depth
  • Working depth 3 - 5”
  • Operating Speed of 8.5 mph minimum up to 14 mph
  • Front row blades on compound 14° open angle and 4° tipped under angle, 22” smooth low concavity blades
  • Rear row blades on compound 17° open angle and 4° tipped under angle, 22” notched low concavity blades
  • Net 5” spacing; 10” spacing per row
  • 4 piece rubber torsion suspension on coulter mounts
  • Blades hubs: Double tapered roller bearing, multi-lip sealed, maintenance free, re-buildable
  • Single point depth control
  • Single point finishing tool pressure
  • Hydraulic fore/aft leveling
  • Hydraulic Wing Down pressure / Accumulator Protection on tilt
  • Factory setup included; minimal finishing tool assembly. Must pin on finishing tools; hydraulics are pre-plumbed

Tires 600/50R22.5

Options

Finishing Options

  • Standard 23" round bar cage roller
  • AVAILABLE SPRING 2021 - Optional 23" rubber packer roller with scraper system
